Kualitas Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan pabrik

Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan

Name: Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan
Brand: Qingdao Henger Shipping Supply Co., Ltd
SKU: Dapat Disesuaikan Sesuai Kebutuhan Pelanggan Diameter minimum 500mm
Price: 7,500.00 USD
Availability: InStock

Atribut Utama

Nama merek: Henger

Nomor Model: Dapat Disesuaikan Sesuai Kebutuhan Pelanggan Diameter minimum 500mm

Tempat Asal: Cina

Sertifikasi: International Quality Management System ISO9001:2000 , Chinese Classification Society ( CCS ) , Det Norske Veritas ( DNV ) , British Lowe ( LR )

Jumlah Pesanan Minimum: 1 buah

Harga: 5000-10000 USD

Kemampuan Pasokan: Pasokan langsung pabrik

Waktu Pengiriman: 7-15 Hari Kerja

Ketentuan Pembayaran: L/C, D/A, D/P, T/T, Western Union, MoneyGram

kemasan standar: kemasan telanjang atau disesuaikan

Ringkasan Produk

pembuatan fender karet harga terbaik dan fender karet kerucut laut dengan kualitas tinggi1. Pengenalan fender karet pneumatikBagaimana cara kerja fender? Pneumatic fender atau inflatable rubber fender atau Yokohama fender udara tekan digunakan sebagai media penyangga untuk menyerap energi benturan ...

Atribut Kustom Produk

Menyoroti

Cone Marine Rubber Fender

,

Docking Anti Collision Marine Rubber Fender

,

Rubber Tube Pneumatic Fender

Bahan:

Karet

Warna:

Putih

Lengan pelindung:

Jaring Rantai Ban, Tabung Karet Untuk Opsi

Masa hidup:

6-10 tahun

AKU P:

50KPa/80KPa (0,05MPa/0,08MPa)

Jaminan:

12 bulan/24 bulan

Aplikasi:

docking anti-tabrakan

Diameter:

0,5m-6m

Panjangnya:

1m-10m

Deskripsi Produk

pembuatan fender karet harga terbaik dan fender karet kerucut laut dengan kualitas tinggi

1. Pengenalan fender karet pneumatik

Bagaimana cara kerja fender?

Pneumatic fender atau inflatable rubber fender atau Yokohama fender udara tekan digunakan sebagai media penyangga untuk menyerap energi benturan kapal, sehingga kapal lebih fleksibel dan fleksibel saat merapat, sehingga dapat mencegah benturan dan benturan.

2.Parameter fender karet pneumatik

Persyaratan kinerja dan ukuran fender 50 pneumatik
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Penyerapan energi terjamin (GEA)	Gaya reaksi pada defleksi GEA (R)	Tekanan lambung (Tekanan internal) pada defleksi GEA (P)
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Nilai minimum pada defleksi 60±5% kJ	Toleransi±10 % kN	Nilai referensi kPa
500x1000	50	6	64	132
600x1000	50	8	74	126
700x1500	50	17	137	135
1000x1500	50	32	182	122
1000x2000	50	45	257	132
1200x2000	50	63	297	126
1350x2500	50	102	427	130
1500x3000	50	153	579	132
1700x3000	50	191	639	128
2000x3500	50	308	875	128
2500x4000	50	663	1381	137
2500x5500	50	943	2019	148
3300x4500	50	1175	1884	130
3300x6500	50	1814	3015	146
3300x10600	50	3067	5257	158
4500 x 9000	50	4752	5747	146
4500x12000	50	6473	7984	154

3.Parameter fender karet pneumatik

Persyaratan ukuran dan kinerja fender pneumatik 80
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Penyerapan energi terjamin (GEA)	Gaya reaksi pada defleksi GEA (R)	Tekanan lambung (Tekanan internal) pada defleksi GEA (P)
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Nilai minimum pada defleksi 60±5% kJ	Toleransi±10% kN	Nilai referensi kPa
500x1000	80	8	85	174
600x1000	80	11	98	166
700x1500	80	24	180	177
1000x1500	80	45	239	160
1000x2000	80	63	338	174
1200x2000	80	88	390	166
1350x2500	80	142	561	170
1500x3000	80	214	761	174
1700x3000	80	267	840	168
2000x3500	80	430	1150	168
2500x4000	80	925	1815	180
2500x5500	80	1317	2653	195
3300x4500	80	1640	2476	171
3300x6500	80	2532	3961	191
3300x10600	80	4281	6907	208
4500 x 9000	80	6633	7551	192
4500x12000	80	9037	10490	202

4.Fitur Fender Karet Pneumatik

Memenuhi persyaratan ISO17357: 2002
2. Lebih aman dan andal
3. Tenaga parkir yang lebih kecil
4. Beradaptasi dengan air pasang
5 Biaya perawatan rendah
6. Reaktivitas rendah dan tekanan lambung
7. Sistem yang paling hemat biaya
8. Keuntungan mengurangi gaya geser
9. Instalasi sederhana dan biaya rendah
10. Ada banyak aksesoris opsional.
Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan 0

5.Transportasi Fender Karet Pneumatik

Transportasi Kami dapat mengambil transportasi palet deflasi dan seluruh transportasi fender tanpa deflasi sesuai dengan kebutuhan pelanggan.Kami selalu mengutamakan kebutuhan pelanggan.

Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan 1

Rubber Tube Cone Marine Rubber Fender untuk Docking Anti Tabrakan 2

Kontak:

Telp/WhatsApp:+86-15053332502
Email: echo-bai@hengergroup.com;
