Kualitas Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut pabrik

Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut

Name: Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut
Brand: Qingdao Henger Shipping Supply Co., Ltd
SKU: HE-HPF
Price: 1,525.00 USD
Availability: InStock

Atribut Utama

Nama merek: Henger

Nomor Model: HE-HPF

Tempat Asal: Cina

Sertifikasi: CCS, ABS, LRS, BV, GL, DNV, NK

Jumlah Pesanan Minimum: 1 pc

Harga: USD 50-3000 PER PIECE

Kemampuan Pasokan: 10 BUAH PER MINGGU

Waktu Pengiriman: 7-15 hari kerja

Ketentuan Pembayaran: D/A, L/C, D/P, T/T, Western Union, MoneyGram

kemasan standar: NUDE/PALET

Ringkasan Produk

Marinir Terapung 3.3x6.5m STS Operasi Pneumatic Fender Karet Fender karet pneumatik Pengantar (1) Bagaimana fender karet pneumatik bekerja? Udara kompres penghangat karet pneumatik digunakan sebagai media penyangga untuk menyerap energi benturan kapal sehingga kapal memiliki fleksibilitas dan ...

Atribut Kustom Produk

Menyoroti

Operasi STS Pneumatic Fender

,

3.3x6.5m Floating Fender

,

Fender karet terapung laut

Nama produk:

Fender Karet Pneumatik / Fender Laut / Fender Yokohama

Bahan:

Karet alam

Ukuran:

0,5*1m~4,5*9m

certification:

CCS/BV/ABS/ISO17357/ISO9001

Warna:

Putih hitam

Aplikasi:

berlabuh/tambat/STS

Jaminan:

24 bulan

Menggunakan kehidupan:

10 TAHUN

Tekanan Pekerjaan:

50kPa/80kPa

Pembayaran:

D/A, L/C, D/P, T/T, Western Union, MoneyGram

Deskripsi Produk

Marinir Terapung 3.3x6.5m STS Operasi Pneumatic Fender Karet

Fender karet pneumatik Pengantar

(1) Bagaimana fender karet pneumatik bekerja?

Udara kompres penghangat karet pneumatik digunakan sebagai media penyangga untuk menyerap energi benturan kapal sehingga kapal memiliki fleksibilitas dan kelenturan yang lebih besar saat berlabuh,Untuk mencegah dampak benturan dan benturan.

(2)JenisFender karet pneumatik

Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut 0

Fender karet pneumatikFitur

Dibangun sesuai dengan ISO 17357-1:2014

Reaksi rendah dan tekanan lambung

Mempertahankan jarak yang besar antara lambung dan struktur

Mudah dan cepat digunakan

Melindungi dari kekuatan luar yang merugikan

Mudah kembung untuk digunakan di lokasi yang berbeda dan untuk disimpan

Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut 1

Fender karet pneumatikParameter

Ukuran dan persyaratan kinerja fender pneumatik 50
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Pencernaan energi terjamin (GEA)	Kekuatan reaksi pada defleksi GEA ((R)	Tekanan lambung (tekanan internal) pada defleksi GEA (P)
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Nilai minimum pada defleksi 60±5% kJ	Toleransi ± 10% kN	Nilai referensi kPa
500 x 1000	50	6	64	132
600 x 1000	50	8	74	126
700 x 1500	50	17	137	135
1000 x 1500	50	32	182	122
1000 x 2000	50	45	257	132
1200 x2000	50	63	297	126
1350 x 2500	50	102	427	130
1500 x 3000	50	153	579	132
1700 x 3000	50	191	639	128
2000 x 3500	50	308	875	128
2500 x 4000	50	663	1381	137
2500 x5500	50	943	2019	148
3300 x 4500	50	1175	1884	130
3300 x 6500	50	1814	3015	146
3300 x 10600	50	3067	5257	158
4500 x 9000	50	4752	5747	146
4500 x 12000	50	6473	7984	154

Ukuran dan persyaratan kinerja fender pneumatik 80
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Pencernaan energi terjamin (GEA)	Kekuatan reaksi pada defleksi GEA (R)	Tekanan lambung (tekanan internal) pada defleksi GEA (P)
Ukuran nominal diameter x panjang mm	Tekanan internal awal kPa	Nilai minimum pada defleksi 60±5% kJ	Toleransi ± 10% kN	Nilai referensi kPa
500 x 1000	80	8	85	174
600 x 1000	80	11	98	166
700 x 1500	80	24	180	177
1000 x 1500	80	45	239	160
1000 x2000	80	63	338	174
1200 x 2000	80	88	390	166
1350 x 2500	80	142	561	170
1500 x 3000	80	214	761	174
1700 x 3000	80	267	840	168
2000 x 3500	80	430	1150	168
2500 x 4000	80	925	1815	180
2500 x 5500	80	1317	2653	195
3300 x 4500	80	1640	2476	171
3300 x 6500	80	2532	3961	191
3300 x 10600	80	4281	6907	208
4500 x 9000	80	6633	7551	192
4500 x 12000	80	9037	10490	202

Fender karet pneumatikMetode Pemasangan

Di kedua ujung fender, pertama belenggu, kemudian sendi berputar, diikuti oleh belenggu lagi
Sebuah rantai pria atau tali pria yang diikat ke belenggu luar.
sendi mencegah memutar rantai pria atau kawat.

Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut 2

Bagaimana fender karet pneumatik D3.3*L6.5m muat ke dalam kontainer 0GP/40HQ?

Langkah 1: Menguras
Langkah 2: Angkat crane
Langkah 3: Pengemasan dan pemasangan ke dalam wadah dengan bantuan forklift

Fender Karet Pneumatik Operasi STS 3,3x6,5m Terapung Laut 4
