Kualitas Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire pabrik

Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire

Name: Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire
Brand: Qingdao Henger Shipping Supply Co., Ltd
SKU: 3300mm x 6500mm
Price: 1,000.00 USD
Availability: InStock

Atribut Utama

Nama merek: Henger

Nomor Model: 3300mm x 6500mm

Tempat Asal: Cina

Sertifikasi: BV/CCS/SGS/LR/DNV/ABS

Jumlah Pesanan Minimum: 1

Harga: $1000-$1000

Kemampuan Pasokan: 99

Waktu Pengiriman: 7-20 hari

Ketentuan Pembayaran: L / C, D / A, D / P, T / T, Western Union, MoneyGram

kemasan standar: Kemasan palet

Ringkasan Produk

Tipe Fender Tipe Hidro-pneumatik Kapal selam dan kapal lain yang menghubungi spatbor di bawah permukaan air memerlukan solusi unik.Fender tipe hidro-pneumatik tipe secara khusus disesuaikan dengan aplikasi ini. Pengantar: Kapal selam dan kapal lain yang menghubungi spatbor di bawah permukaan air ...

Atribut Kustom Produk

Menyoroti

Tipe Fender Tipe Pneumatik

,

Fender Tipe Pneumatik Kapal Angkatan Laut

,

Fender Karet Pneumatik Kapal Angkatan Laut

Bagian:

peralatan laut, Flange, Pneumatic Boat Fender, Marine fender, pneumatic rubber fender

Warna:

Hitam, Biru, Hitam/Sebagai Persyaratan, Semua warna dapat diterima, Hitam/Putih atau warna apapun

Bahan:

Karet Alam, EPDM, SBR, SILIKON, EVA

Aplikasi:

STD, STS, Kapal dan Kapal, Fender kapal, Marine / quay / dock / boat

Ukuran:

Disesuaikan, Fender karet pneumatik D3.3 * L6.5m, SEMUA, 2 * 3.5m, 3.3x6.5m

Nama:

pneumatic rubber fender, Pneumatic Boat Fender, Marine Floating Pneumatic Inflatable Rubber Fender U

Nama Produk:

Fender karet pneumatik, fender Laut / Dok

Periode garansi:

24 bulan, 3 tahun

Tipe:

DO, 50Kpa, Pneumatik, D, perlindungan UV

Pengepakan:

Kemasan normal, Packing Nude / Sesuai Kebutuhan, Paket Standar

Jaminan:

24 bulan

Diameter:

0,5m-3,3m, 0,5 ~ 4,5m

Sertifikasi:

CCS BV certification ISO17357 ISO9001,ABS,DNV,LR,CCS

Pemakaian:

Fender kerucut laut pneumatik, Melindungi kapal selama operasi kapal-ke-kapal atau tambat di dermaga

Panjangnya:

0.5m~12.0m,1.0m-6.5m,1~9m

Rantai:

312, galvanisasi panas atau baja tahan karat (304.316)

Kualitas:

Luar biasa

Desain menggunakan kehidupan:

10 tahun

Fitur:

Resistensi penuaan

Deskripsi Produk

Tipe Fender Tipe Hidro-pneumatik

Kapal selam dan kapal lain yang menghubungi spatbor di bawah permukaan air memerlukan solusi unik.Fender tipe hidro-pneumatik tipe secara khusus disesuaikan dengan aplikasi ini.

Pengantar:

Kapal selam dan kapal lain yang menghubungi spatbor di bawah permukaan air memerlukan solusi unik.Fender tipe hidro-pneumatik tipe secara khusus disesuaikan dengan aplikasi ini.Badan fender sebagian diisi air, kemudian diberi tekanan dengan udara dan diberi pemberat untuk membuatnya berdiri secara vertikal, rancangan dan kinerja fender dapat disetel dengan mengubah rasio air: udara dan tekanan inflasi.

Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire 0

Detail dari Jenis ⅵ fender tipe hidro-pneumatik:

Ukuran spatbor diameter * panjang /mm	Tekanan internal awal 50kPa		Tekanan internal awal 80kPa
Ukuran spatbor diameter * panjang /mm	Energi terjamin penyerapan (GEA)	Nilai referensi kPa	Energi terjamin penyerapan (GEA)	Nilai referensi kPa
500x1000	6	67	8	85
600x1000	8	74	11	98
700x1500	17	137	24	180
1000x1500	32	182	45	239
1000x2000	45	257	63	338
1200x2000	63	297	88	390
1350x2500	102	427	142	561
1500x3000	153	579	214	761
1700x3000	191	639	267	840
2000x3500	308	875	430	1150
2500x4000	663	1381	925	1815
2500x5500	943	2019	1317	2653
3300x4500	1256	1884	1752	2742
3300x6500	1814	3015	2532	3961
3300x10600	3067	5257	4281	6907
4500x12000	6473	7984	9037	10490

Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire 1

Jenis ⅵ Fitur fender tipe hidro-pneumatik:

Kinerja dapat disesuaikan dengan mengubah rasio udara-air

Draf yang diperlukan dapat disesuaikan

Tekanan lambung rendah

Pengaturan diri saat air pasang berubah

Biaya pemasangan dan perawatan rendah

Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire 2

FAQ:

1. "Saya memiliki spesifikasi kapal selam, tetapi saya tidak tahu bagaimana memilih ukuran spatbor kapal selam. Bisakah Anda membantu saya?"

Jawaban: Anda tidak perlu khawatir sama sekali.Kami memiliki lebih dari 20 tahun pengalaman produksi dan penjualan.Selama Anda memberi saya parameter yang sesuai, kami dapat menyarankan ukuran dan jumlah spatbor kapal selam yang sesuai untuk Anda.

2. "Saya ingin mencoba spatbor kapal selam Anda, tetapi saya belum pernah menggunakannya, dan saya tidak tahu cara menggunakannya. Bisakah Anda membantu saya?"

Jawaban: Anda tidak perlu khawatir sama sekali.Kami akan memberi Anda petunjuk saat pengiriman, dan mengirimkannya bersama dengan spatbor kapal selam.Anda dapat menghubungi saya jika Anda memiliki pertanyaan selama instalasi dan penggunaan nanti.

3. "Berapa jumlah pesanan minimum untuk spatbor kapal selam Anda?"

Jawaban: Jumlah pesanan minimum kami adalah 1 PC.

Jenis Hydro Pneumatic Type Fender Naval Ships Pneumatic Rubber Fender Chain Tire 3

Layanan Henger:

1. Hener memiliki layanan VIP satu-ke-satu.

2. Hener memiliki layanan purna jual seumur hidup.

3. Hener akan merekomendasikan ukuran dan jumlah spatbor kapal selam yang sesuai dan saran profesional lainnya untuk Anda sesuai dengan situasi aktual dan parameter yang diberikan oleh pelanggan.

4. Setiap pertanyaan tentang spatbor bawah air akan dijawab dalam waktu 24 jam.

5. Ajari pelanggan untuk menggunakan perisai kapal selam kami di lokasi.
